Product Details:
|
| Frame Material: | Aluminum Alloy | Opening Pattern: | Horizontal |
|---|---|---|---|
| Screen Netting Material: | Stainless Steel | Warranty: | More Than 5 Years |
| Material: | Aluminum, Aluminum Alloy+Glass+Accessories | Feature: | Magnetic Screen, Folding Screen |
| Open Style: | Folding | Function: | Heat Insulation, Heat Insulation |
| After-sale Service: | Return And Replacement, Onsite Inspection, Online Technical Support, Onsite Training, Onsite Installation, Free Spare Parts | Project Solution Capability: | Total Solution For Projects |
| Application: | Leisure Facilities | Design Style: | Chinese |
| Curtain Type: | Hanging | Product Name: | Aluminum Bi-fold Window |
| Glass: | Single\double\tempering\coating\low-e | Hardware: | Chinese Top Brand |
| Surface Treatment: | Powder Coated | Glass Color: | Clear\gray\blue\green\brown |
| Style: | Modern Simple | Packing: | Wooden Case |
| Open Type: | Sliding Horizontal | Port: | QINGDAO,TIANJIN,NINGBO,SHAGNHAI,GUAGNZHOU,SHENZHEN |
Profiles | Series | 1. 6063-T5 high quality thermal break aluminium profiles 2. 6063-T5 high quality non-thermal break aluminium profiles Commonly used series:50mm: 50series max-glass-thickness:22mm | |
Thickness | 1.4/1.6/2.0mm | ||
color | Brown\ dark grey\light grey\ black\star black,etc. | ||
Glass | Types | Low-e glass\frosted glazing\ grey/blue/green tinted glass,etc. 1.Single:3mm~12mm 2. Double: 5mm 6A 5mm/5mm 9A 5mm/6mm 9A 6mm, etc. 3.Triple: 5mm 6A 5mm 6A 5mm and others 4.Tinted/Reflected/Frosted Glass (Tempered Glass) | |
Thickness | 4-19mm | ||
color | clear/super clear/ tinted blue/green/coffee brown/gray | ||
Shreshold | Low：13.31mm-24mm Higher:35mm-50mm | ||
Folding Way | Odd or Even Number Folding | ||
Hardware | Brand:Germany brand (Siegenia /Roto )\Australia brand\China brand Aluminum alloy folding windows accessories combination: Accessories combination: handle + lock catch + hinge +EPDM sealing strip | ||
Mesh | Stainless steel security mesh\Aluminum security mesh Fiberglass flyscreen\Retractable flyscreen | ||
Finish | Powder coating \ Anodized \ Electrophoresis Wood grain\Sliver& Champagne\PVDF | ||
Advantages | 1. Big opening area and save indoor space. Good air mobility, good daylighting. 2. Well sealed, heat thermal insulation performance is superior, good airtightness, good watertightness, better security. But the cost is high. 3. Adapt to different buildings and places, with various colors, high strength, acid and alkali resistance, 4. corrosion resistance, long service life, good thermal insulation, simple installation, high, medium and low quality products can be selected. | ||
